PART NUMBER: DRV N520
Recorded videos can be displayed on the large screen, and operated from the touch panel.
DRV-N520 is equipped with the safety alert function which can be activated or deactivated. Dangerous situations such as an unintentional lane departure or forward collision are detected and a beep sound and caution pop-up is displayed on the multimedia system.
| 1/3 inch Color CMOS |
| Bright (F2.0) & Wide Viewing Angle Lens |
| Ultra Compact Design |
| Linkage with compatible multimedia units |
| Built-in "Save driving features" |
| Built-in G-Sensor |
| Equiped with HDR technology |
| Support Super HD Video Recording |
| 27 frames/Second Smooth Recording |
| Kenwood Drive Reviewer, PC Application |
| Image Sensor | 1/3" Colour CMOS |
| Number of Pixels | 3M Pixels (2304 x 1296) |
| Lens Type | Bright (F2.0) Wide View Lens |
| Viewing Angles | 117(H) / 63(V)/ 128(Diagonal) |
| Event Recording Mode | Yes |
| Continuous Recording | |
| Manual Recording | Yes |
| Parking Recording | Yes |
| Recording preservation timing | Full Time/Event/Manual/parking |
| Recording time for collision detection | |
| Recording time before the collision detection | |
| Recording time after the collision detection | 10/30/60sec |
| Frame Rate | 27 fps |
| Photo Format | JPEG |
| Photo Size | 2304 x 1296 Pixels |
| Video Format | MOV |
| Video Codec | H.264 |
| Video Clip Lenght | 1/2/3 min |
| Audio File Fomat | Linear Pulse Code Modulated Audio (LPCM) |
| G-Sensor Built-in | -4G to +4G (0,1G steps) |
| HDR record enhancement | On / Off (Default) |
| Scene Select Technology | Yes |
| Parking surveillance mode | with optional hardwired kit |
| Forward Collision Warning (FCW) | Yes |
| Lane Departure Warning (LDW) | Yes |
| Departure Delay Warning (DDW) | Yes |
| Recording Media | micro SDHC Class 6 or over |
| Maximum Size Recording Media | 4GB up to 32 GB |
| Dash Cam Link with Compatible KENWOOD Unit | Yes |
| Power Supply type | 3,5m DC-cable |
| Power Supply voltage | 12V(8,5 to 16V) |
| Current Consumption | 400 mA |
| Dimensions | 79 x 22 x 48 mm |
| Weight | 77 gr (Camera Only) |
| Car Mount Bracket | Included |
| PC application | via download |
