Blue Sea 187-Series Circuit Breaker - 40A

(No reviews yet) Write a Review

Current Stock: 30

£85.12

RRP: £93.92

You save £8.80

Quantity:

DISPATCHED IN 5 WORKING DAYS

Or

N/A

N/A

Blue Sea Systems 187-Series Circuit Breaker

PART NUMBER: 8-27038

Provides heavy duty circuit protection for 25 to 200 Amp loads when switching and circuit protection are both required.
Self-trimming case eliminates need for mounting panels or trim bezels
Round case for easy installation with standard sized hole saw (panel mount)
Regulatory
CE marked
Meets SAE J1171 external ignition protection requirements
IP66 - protected against powerful water jets
Combines switching and circuit protection into a single device*
Clear, single lever operation
"Trip Free" design cannot be held "ON" during fault current condition
Waterproof
Recessed mounting holes for clean appearance
Large Clearance around terminal studs accept heavy gauge wire lugs
Robust 5/16 M8 terminals provide high torque connections
Large lever with vertical/horizontal orientation provides indication of trip status
Ignition protected - Safe for installation aboard gasoline powered boats

* Do not use as a switch where high inrush currents are expected.

Brand	Blue Sea Systems
Amperage	40A
Maximum Voltage	48V DC
Mounting	Panel Mount
Circuit Breaker Type	Thermally responsive Bi-metal blade
Terminal Stud Torque	75 in-lb (8.47 Nm)
Interrupt Capacity	5000A @ 14VDC
	3000A @ 28VDC
	1500A @ 48VDC
Minimum Operating Temperature	-40 C
Maximum Operating Temperature	85 C
Case Material	Thermoset Polyester
Circuit Breaker Class	Type III - switchable/manual reset - trip free
Mounting Hole	Accept #10 (M5) Screw
Terminal Stud Size	5/16" - 18
